All colours shown are digital simulations, and actual bike colours may differ. Variations can be influenced by factors like indoor lighting and outdoor brightness, although we make every effort to accurately replicate the colour palettes.
Single Speed -DT Swiss
Utilizing DT Swiss components for unmatched quality, single-speed e-bikes offer a simplified, reliable cycling experience. With no need for gear shifting, maintenance is minimal, and the ride is smooth. The motor's assistance ensures easy incline climbing and adaptability, making these bikes perfect for both urban commutes and leisurely rides, appealing to a broad range of cyclists.
Dual Speed - Classified
Classified's Powershift technology introduces a groundbreaking approach to gear shifting with its wireless, instant changes achievable under full load. Initially developed to improve aerodynamics on road bicycles by doing away with the front cassette, the Classified team has extended its utility to serve every aspect of cycling.
14 Speed -Rohloff E14
The Rohloff E14 is a high quality, precision bicycle transmission. Providing a proven, durable construction and outstanding performance coupled with extremely low maintenance costs.. Features 14 gears within an oversized hub, ensuring optimal gear distribution for any terrain. This gear range offers a 526% spread, delivering unparalleled efficiency in bicycle hub gearing.
High Modulus Carbon Fibre Monocoque
Data Sheet
Material
Carbon Fibre
E Fitment
Bosch Performance Line CX
Cable Management
Fully Integrated
Battery
Fully Integrated
Top Tube Cover
Fully Integrated Bosch Kiox
Fully Integrated One Piece Cockpit
Data Sheet
Material
Carbon Fibre
Bar Offset
50mm
Rise
20mm
Upsweep
5 Degrees
Stem
One Piece Carbon Fibre
Motor Settings
Data Sheet
Motor Settings
Eco, Tour, Sport, Turbo, eMTB
Weight
2.9kg
Torque
85Nm
Maximum Support
340%
Max Speed
25km/h
Titanium Drive System
Data Sheet
Belt Tensioner
TI-6AL-4V Titanium
Snubber
TI-6AL-4V Titanium
Eccentric Wheel
TI-6AL-4V Titanium
Evari Bolt Package
TI-6AL-4V Titanium
Evari Drop Outs
Carbon Fibre
Supernova Fully Integrated Lights
Data Sheet
Headlight
Supernova Mini 2 Integrated
Watts
4.8W
Lumens
235lm
Material
AL6061
Material
Steel Ball Blasted Matt Black Anodized
Bespoke for the 856
Data Sheet
Material
Carbon Fibre
Rim Diameter
29"
Width
45mm
Profile
19mm
Hole
32
Fully Integrated 2 Piece Cockpit
Data Sheet
Material
Carbon Fibre
Bar Offset
50mm
Rise
20mm
Upsweep
5 Degrees
Stem
Alloy 6082 with 7075 Clasp
Carbon Fibre Top Tube Integration
Data Sheet
Computer
Bosch Kiox
Connectivity
Bluetooth
Walk Assistance
Smart Walk Assist
Activity Tracking
Auto track tour and fitness
eBike Lock
For additional theft protection
Total Electronic Integration
Data Sheet
Hoses
Quick release hoses for ease of servicing
Electric Cables
Fully Integrated & Quick Release
Headlight
Supernova Integrated
Tail Light
Supernova T-M99TL2
Computer
Bosch Kiox
Size Guide
Medium: 1.52m - 1.67m
Large: 1.65m - 1.90m
Relaxed yet sporty riding position, designed for both comfort and efficiency. Ideal for daily commuting and long-distance rides, it combines an ergonomic posture with performance-oriented geometry to ensure a comfortable journey without compromising on speed and agility.
If you would like more information on the geometry for each model size, please contact hello@evaribikes.com.
EVARI 856 ST
Carbon Monocoque Frameset
Bosch CX Performance Line
Integrated Bosch Kiox
Evari Carbon Rims (Gloss)
DT Swiss 350 Hubs
Praxis Alloy Crank Arms
Schwalbe G-One Tyres
Ex-Factory Paintwork (3 Colours)
856
Carbon Monocoque Frameset
Bosch CX Performance Line
Integrated Bosch Kiox
Evari Carbon Rims (Gloss)
DT Swiss 350 Hubs
Praxis Alloy Crank Arms
Schwalbe G-One Tyres
Ex-Factory Paintwork (3 Colours)
Choice of Single Speed
Choice of Classified Dual Speed
Choice of Rohloff E14 Speedhub
One-piece carbon cockpit
EVARI 856 CS
Carbon Monocoque Frameset
Bosch CX Performance Line
Integrated Bosch Kiox
Evari Carbon Rims (Matte)
DT Swiss 240 Hubs
Praxis Carbon Crank Arms
Schwalbe G-One Tyres
Paintwork by Kustomflow in UK
Choice of Single Speed
Choice of Classified Dual Speed
Choice of Rohloff E14 Speedhub
One-piece carbon cockpit
Thank you for purchasing an Evari product. It’s important to us that you are completely satisfied with your bike. However, if issues should arise, please follow the instructions laid out below in order to inform us of any problems.
Evari warranty includes for the original owner the frame, fork, handlebars and original component parts of each new Evari brand bicycle to be free from defects in material and workmanship for a 2 year period from date of delivery and only for material defects that already existed on delivery.
On the delivery date of the bike to the first owner, if the bike appears to have suffered damage during transit please contact Evari within one working day of receiving the bike to register the defect. Any defects caused as a result of shipping will be rectified by Evari.
Any Evari component failure attributable to faulty materials or workmanship during manufacture will be rectified free of charge by Evari for two years from the date that the bike is delivered to the first owner.
For two years, from the date that the bike is delivered to the first owner, any defect of the Carbon monocoque+ attributable to faulty materials or workmanship during manufacture will be rectified free of charge by Evari.
The term “defect of the carbon monocoque+” refers to de-lamination of any carbon surface throughout the frame, forks, handlebars and seat post causing a weakness to develop.
All other original bike components supplied by other manufacturers (non-Evari) shall be subject to the warranty provisions of the manufacturer in question.
Register your warranty request by sending a photo of your bike and receipt, and email to us along with your order number. Once we have approved the request we will arrange shipment of your bike back to us to check.
Natural wear of parts such as brake pads, brake discs, seals, slide rings, handlebar grips, chains, bearings, tyres, shifting components, foam parts, spokes. Any technical modifications of the bike by the buyer and any modifications to the version delivered, including repainting. Non Evari components and parts. Damage caused by normal wear. Damage due to unsuitable cleaning agents. Damage caused by failing to follow the owner’s manual. Bicycles serviced by anyone other than a Bosch registered service centre. Accidental damage caused through collision with an object or person or as a result of dropping the bike or the bike falling over.
We do not recommend 'chipping' the motor of your electric bike as this may make the bike illegal under the country's law in which you are riding. It should also be noted that the manufacturer of the motor may void the warranty should they find out that the motor has been tampered with.
Please let us know which country your Evari will be ridden in and we will endeavour to fit the correct motor specified for that country.
The Bosch CX Performance Line motor weighs 2.9kgs
The motor produces 85Nm of torque
The Bosch motor has a 2 year warranty as standard if the product is not used in a commercial capacity.
Rohloff offer a 2 year warranty as standard.
The Rohloff E-14 has been developed with a focus on maximum durability and efficiency. Very few maintenance procedures are required so ensure this system remains in top condition.
We believe Rohloff have an incredible track record in reliability and are frequently chosen by long distance cyclists who want a fit and forget system with very little maintenance. We also believe the gear range offers the rider the ability to tackle any gradients they might face
We believe for most city environments without any major hills, one gear is a great simple, fuss free option. Please talk to us further to see if a single speed works for you.
Yes we can supply the necessary bearings for your wheels. They should last a long time as DT Swiss are renowned for the quality and longevity, if in the event that they are feeling loose or slightly gritty, we can replace them for you. These will be available in our app store
Front hubs are 110mm Boost and 142mm Rear
E-bikes have an increased amount of torque running through the rear wheel so we use the best spokes possible for our E-bikes. Sapim are one of the world leaders in spokes and we use their butted spokes called the 'strong spoke'. We can supply spares if needed
The trend to wider rims on road and mountain bikes is mainly to give the tyre a more rounded profile on the rim. This aids traction and rolling resistance
Not as standard, but they are tubeless compatible and this can be achieved quite easily with 42 mm rim tape from Schwalbe and tubeless tyre valves. We would also recommend using an appropriate sealant if you intend to install tubeless tyres. Please also ensure that the tyres are tubeless compatable.
Between 16kg - 19kg depending on the setup
Titanium is incredibly strong and lightweight and is a perfect material for our fixings. Furthermore all our titanium screws have a PVD black coating (Physical Vapour Deposition) and are laser etched.
We use aerospace grade 6al 4v spec titanium
From the time of order placement to despatch we anticipate a lead time of 14-28 days, however, we will notify you of longer lead times if your requests for paintwork require more sourcing and development time.
Yes, we can supply saddles from Selle Italia but we have chosen the Novus Boost TM for its great comfort so we are pertty sure you will like it. This from Selle Italia:
Created with pure comfort in mind, the Novus Boost Evo TM Superflow is ideal for epic rides through the most challenging of landscapes. Completely redesigned from the ground up, this saddle is lightweight and comfortable thanks to its wave profile. This evolved design supports your ischial bones on long rides and Superflow cut-out reduces pressure on the perineum. The Manganese rails and short nose improve pedalling ergonomics, manoeuvrability, comfort and performance.
Please inform us upon the purchase of your Evari to ensure your warranty relates reasonably to your purchase date. If you have a warranty request, please contact us at hello@evaribikes.com and we will work with you to solve the problem together.
Yes, we have attachments for mudguards, the mudguards are currently in development and will be released soon. We are producing these ourselves and will suit the bikes aesthetic as well as being highly functional.
There is a maximum rider weight of 125Kgs
If you are based in the UK, please give us a call and we can arrange a location.
Not at present but this is something we are looking into.
We would advise against the use of a jet wash around an electric bike. Although all components have a waterproof rating, the forces from jet washers can eventually create water ingress issues.
Your 856 bike is rated for light gravel/towpath off-road use, however, we do not advocate jumping on your bike as it is not designed with suspension front or rear. We would stress that the standard tyres are rated for light gravel use only.
Yes you can, however, the light may be obscured and so won't be suitable for night riding use if this is the case. Please always ensure that your lights are in full working order and the beams are not obscured whenever riding in the dark.
It depends how you like the bike to feel and we can adivse if in doubt, however, as a general guide please look at the frame details in the above geometry section.
If you take a look at our configurator, you will find a comprehensive list of colour options. This will be updated frequently, and we can mix any colour and finish you can imagine!
This is a common question for many eBikers. There is no definitive answer. The number and variety of influential factors is simply too great. Sometimes a single battery charge will take you less than 20 kilometres, while at other times it will take you much further than 80 kilometres.
Usually, airlines do not allow lithium-ion batteries with a capacity greater than 100Wh. Please enquire with your airline before travelling Most likely, you will have to arrange a battery at your destination or ship the battery separately by land (following the regulations for hazardous goods Class 9).
The battery can be charged by taking the unit off (if you need to charge it e.g. at your desk) or by using the onboard charger situated above the motor integrated in the frame.
We ship all Evari's with the Bosch Fast Charger which charges to 50% in 1.2h and full capacity in 3h.
Your battery can remain in the bike whilst not being used, or simply take it out and store in a safe place.
No, with a modern Lithium ion battery there is no need to completely displace the battery prior to a charge
Please leave the battery in the bike during cleaning. The battery is concealed in the frame and along with the carbon fibre cover, it helps to prevent water ingress during cleaning.
We would recommend Magura pads, although there are numerous versions of after market brake pads available.
Yes we can set up the brakes to how you prefer and will ask you at the time of preference, as we export bikes around the world.
We spec 203 mm front rotors and 180 mm rear rotors for maximum brake performance.
Disc brakes can occasionaly require bleeding to take excess air out of the system. The mineral fluid in Magura brakes is of the highest quality, and the brakes are fully bled prior to shipment so under normal use we wouldn't anticiapte them requiring a re-bleed for at least 300 hours use.
DT Swiss 370 Hub
Meticulously engineered for optimal performance, this hub ensures smoothness and durability on every ride. Its innovative design minimizes friction, translating your effort into impressive speed. With a sleek and functional design, the DT Swiss 370 Hub is the perfect choice for cyclists who demand high-quality precision in their equipment
The DT Swiss 370 Hub's sleek aesthetics are matched only by its exceptional functionality, making it an ideal choice for cyclists who demand nothing short of perfection. Whether you're tackling gravel or embarking on long road journeys, trust in the DT Swiss 370 Hub to provide the reliability and responsiveness that avid cyclists crave.
DT Swiss 350 Hub
Thanks to the proven freehub Ratchet System, the 350 hub is a dependable partner for every adventure. The 36 tooth ratchets ensure direct power transmission. The sophisticated yet simple construction of the hub allows a low weight while providing outstanding rolling performance.
DT Swiss 240 Hub
The new 240 is developed for riders with the most extreme ambitions. The latest version of the hub is equipped with the Ratchet EXP system to maximize reliability. The increased bearing distance increases bearing lifetime, the straight spring provides more direct engagement, which reduces wear, and a smaller number of parts not only makes maintenance easier but also reduces weight.
Classified Powershift 2 Speed Hub
Powershift Technology is a wireless shifting technology that allows you to shift gears instantly and under full load.One launch gear and one cruising gear, able to shift while standing still, lightweight, intuitive and highly efficient. A wireless 2 speed shifting system, integrated in the rear hub.
The Powershift hub offers unrivalled shift quality, high gearing range and small steps in between gears combining the benefits of both 1x and 2x
• Instant shifting - 150 miliseconds, that’s all it takes
• Shift under full load - Up to 1000 watts
• Weatherproof -No need to worry about dirt or rain.
Rohloff E14 Speedhub (Electronic Shifting)
The electronic Rohloff E-14 shifting system raises the bar for shifting E-bikes transmissions. The new E-14 from Rohloff synchronizes perfectly with the mid-motor, Bosch eBike system to operate the now legendary Rohloff SPEEDHUB 500/14.
One push of a button is all it takes to automatically reduce motor derived force upon the transmission and shift the SPEEDHUB. If the button is kept held, then the E-14 shifting system will shift 3-gears at a time in sequence, through all 14 gears if so desired. In addition, once the sensors note the cyclist has become stationary, the E-14 system will automatically shift to a pre-programmed gear to start off again. The Rohloff E-14 is the most efficient and durable shifting system available for mid-motor E-bikes.
Suggested height for Small/Medium 1.52m - 1.67m
Suggested height for Large/Extra Large 1.65m - 1.90m
If you would like more information on the geometry for each model size, please contact hello@evaribikes.com.
All colours are digital representations and the colour may vary from the actual bikes. Factors such indoor lighting and sky brightness will also have an impact, although we strive to match to the colour palettes wherever possible.
DT Swiss 370 Hub
Meticulously engineered for optimal performance, this hub ensures smoothness and durability on every ride. Its innovative design minimizes friction, translating your effort into impressive speed. With a sleek and functional design, the DT Swiss 370 Hub is the perfect choice for cyclists who demand high-quality precision in their equipment
The DT Swiss 370 Hub's sleek aesthetics are matched only by its exceptional functionality, making it an ideal choice for cyclists who demand nothing short of perfection. Whether you're tackling gravel or embarking on long road journeys, trust in the DT Swiss 370 Hub to provide the reliability and responsiveness that avid cyclists crave.
DT Swiss 350 Hub
Thanks to the proven freehub Ratchet System, the 350 hub is a dependable partner for every adventure. The 36 tooth ratchets ensure direct power transmission. The sophisticated yet simple construction of the hub allows a low weight while providing outstanding rolling performance.
DT Swiss 240 Hub
The new 240 is developed for riders with the most extreme ambitions. The latest version of the hub is equipped with the Ratchet EXP system to maximize reliability. The increased bearing distance increases bearing lifetime, the straight spring provides more direct engagement, which reduces wear, and a smaller number of parts not only makes maintenance easier but also reduces weight.
Classified Powershift 2 Speed Hub
Powershift Technology is a wireless shifting technology that allows you to shift gears instantly and under full load.One launch gear and one cruising gear, able to shift while standing still, lightweight, intuitive and highly efficient. A wireless 2 speed shifting system, integrated in the rear hub.
The Powershift hub offers unrivalled shift quality, high gearing range and small steps in between gears combining the benefits of both 1x and 2x
• Instant shifting - 150 miliseconds, that’s all it takes
• Shift under full load - Up to 1000 watts
• Weatherproof -No need to worry about dirt or rain.
Rohloff E14 Speedhub (Electronic Shifting)
The electronic Rohloff E-14 shifting system raises the bar for shifting E-bikes transmissions. The new E-14 from Rohloff synchronizes perfectly with the mid-motor, Bosch eBike system to operate the now legendary Rohloff SPEEDHUB 500/14.
One push of a button is all it takes to automatically reduce motor derived force upon the transmission and shift the SPEEDHUB. If the button is kept held, then the E-14 shifting system will shift 3-gears at a time in sequence, through all 14 gears if so desired. In addition, once the sensors note the cyclist has become stationary, the E-14 system will automatically shift to a pre-programmed gear to start off again. The Rohloff E-14 is the most efficient and durable shifting system available for mid-motor E-bikes.
